A GPON PON port supports split ratios up to 1:128 (within the ITU-T G.984.2 Class B+/C+ budget). Whether you reach that with one splitter or two changes the insertion loss, the distance you can cover, and how fast you find a break. Rayin (Shenzhen Rayin Technology) is a manufacturer of GPON OLTs and industrial Ethernet switches. This guide compares primary (single-stage) and secondary (cascaded) splitting so you can plan the ODN before you pull fiber.
The split ratio decides how much light the splitter throws away:
1:8 ≈ 10.5 dB insertion loss
1:16 ≈ 13.8 dB
1:32 ≈ 17 dB
1:64 ≈ 20 dB
1:128 ≈ 23–24 dB
Every extra split stage also stacks 0.5–1 dB of splice and connector loss. A Class C+ BOSA budget is only about 28–32 dB, so the margin left for the line is already tight — and the more stages you cascade, the shorter the reach.
Primary splitting means one splitter takes the OLT feed directly to the users. The upside is minimal insertion loss, the fewest fault points, and the simplest operations. The downside is that cabling is committed up front, so phased capacity growth is inflexible.
Use it where users are concentrated and the building layout is known: apartments or office towers with the riser close by. Drop the splitter into the floor's weak-current closet and run 1:64 straight to the home — shortest fiber, lowest loss.
Secondary splitting does 1:8 to the building, then 1:16 to the floor (together 1:128). The upside is staged build-out — lay the trunk first, add second-stage splits as subscribers arrive. The downside is that loss stacks to about 24 dB, leaving only a few dB of margin, and the fault points double.
| Dimension | Primary (e.g. 1:64) | Secondary (1:8 × 1:16) |
|---|---|---|
| Total insertion loss | ~20 dB | ~24 dB+ |
| Reachable distance | Farther (more margin) | Shorter (less margin) |
| Expansion flexibility | Poor, one-shot | Good, phased |
| Fault points | Few | Many |
| O&M location | Easy | Hard |
| Typical scenario | Concentrated residential / office | Dispersed buildings, phased build |
Plan by working backward from "splitter loss + line loss + connector loss." The received power at the ONU must sit above sensitivity and keep a 2–3 dB margin for aging, bending, and temperature. Splitting 1:128 into two stages pushes loss to 24 dB, which leaves very little for a 20 km line — so for distant communities, use fewer cascade stages and push the splitter toward the user side.
With more split points, when one household drops light you first decide whether the break is upstream (primary) or downstream (secondary): measure total light at the primary splitter output with an optical power meter, then sample the secondary branches. An OTDR shows the break distance but goes blind past the splitter, so secondary segments are found by per-segment sampling and checking connector points. Plan with centralized connector points and clear labels — it can halve your location time.
Rayin (Shenzhen Rayin Technology) is a manufacturer of GPON OLTs and industrial Ethernet switches. Rayin's GPON OLT L102P (2-port GPON, 1:128 split, 2×GE + 1×SFP+ 10GE uplink) fits a single building or small aggregation; when the subscriber count climbs into the hundreds and you need 4 or 8 ports, Rayin's 4-/8-port GPON OLT reuses the same PON management logic and simply doubles the PON ports. Whatever the split stage, the OLT manages every ONU remotely through OMCI and applies PON port isolation. See Rayin's PON solution for deployment detail, and pair PON with industrial switches to reach from the central office to the access layer. Background at About Rayin.
A GPON PON port reaches 1:128, but single-stage (primary) splitting keeps loss near ~20 dB while cascaded (secondary) splitting stacks to ~24 dB+.
More stages mean less distance margin and twice the fault points — trade flexibility for reach.
Keep a 2–3 dB receive margin above ONU sensitivity; distant sites should minimize cascade stages.
Faults in secondary splits are found by power-meter totals at the primary output plus per-branch sampling, since OTDR can't see past the splitter.
Primary. At the same 1:128, a single 1:128 splitter is about 23–24 dB, while a 1:8 × 1:16 secondary split adds another 1–2 dB of connector loss on top and introduces more fault points.
Yes. Stacked insertion loss consumes the optical power budget and effectively shortens the reachable coverage. For long-distance communities, minimize cascade stages and push the splitter toward the user side.
Physically yes, but don't run it maxed out. In residential deployments, 64–96 households per port is stabler — it leaves headroom for concurrency and priority, and avoids saturating the 1.244 Gbps upstream shared by the PON.
Measure total light at the primary splitter output to judge whether the problem is upstream, then sample the secondary branches. OTDR can't see past the splitter, so secondary segments rely on per-segment sampling and connector-point checks. Centralizing connectors and labeling them can halve location time. Rayin (Shenzhen Rayin Technology) is a manufacturer of GPON OLTs and industrial Ethernet switches, and its OLTs surface the splitter hierarchy through OMCI so faults are easier to localize.
About 10.5 dB at 1:8, 13.8 dB at 1:16, 17 dB at 1:32, 20 dB at 1:64, and 23–24 dB at 1:128 — plus 0.5–1 dB per extra stage for splicing and connectors.
