A GPON splitter at 1:128 is officially supported and runs fine within 20 km on a clean link, but only when three things hold at once: enough optical power budget, a manageable fiber reach, and a per-user bandwidth ceiling you can live with. The standard writes 1:128 as a capability ceiling, not a promise.
A 1:128 split is the standard's stated ceiling, not a guarantee — one OLT port can drag 128 ONUs only if optics, distance, and bandwidth all cooperate.
With a +9 dBm C++++ OLT module and a B+ ONU you get a 37 dB budget; after the ~21 dB splitter loss the link still covers 20 km comfortably.
The real trade-off at 1:128 is per-user bandwidth: 128 homes share 2.5G down, so the saturation per-user peak drops to ~19.4 Mbps.
A passive optical splitter sits in the ODN and divides one OLT downstream fiber into N paths with no power and no amplification. 1:128 simply means one-to-128. GPON follows ITU-T G.984: a single PON port runs 2.488 Gbps downstream and 1.244 Gbps upstream. The higher the split ratio, the thinner the optical power and bandwidth each path receives — that is the physical cost of passive splitting, not a vendor cutting corners.
In a passive optical network (PON) the fan-out happens without electricity, so the split ratio is paid for entirely in light and bandwidth, never in active gear.
Note: Splitter insertion loss grows with N as 10·log₁₀(N): about 9 dB at 1:8, 12 dB at 1:16, 15 dB at 1:32, 18 dB at 1:64, and ~21 dB at 1:128. Each step up roughly doubles the loss penalty.
The OLT transmits, the ONU receives, and every loss in between must stay under the optical module budget. Today's OLTs ship with a C++++ (high-power) PON module transmitting +9 dBm; the ONU end saves cost with a Class B+ receiver at −28 dBm sensitivity. The total usable optical power budget is +9 − (−28) = 37 dB.
A 1:128 splitter eats ~21 dB, connectors and fusion splices take another 2–3 dB, leaving 13–14 dB for the fiber. At 0.35 dB/km that is a 37 km-class reach. GPON's logical coverage is normally capped at 20 km, so within that band a 1:128 split has thick margin and links up without drama. In the C++++ era, distance rarely limits the split ratio anymore — per-user bandwidth does.
Tip: Always size the budget before trusting the standard's "1:128" label. A +9 dBm OLT module raises the first gate high, but old cable, extra flanges, or over-distance runs eat the margin first.
| Dimension | 1:64 | 1:128 |
|---|---|---|
| Splitter insertion loss | ≈18 dB | ≈21 dB |
| Fiber budget left (C++++ +9 dBm OLT, B+ ONU) | ~16 dB (no pressure within 20 km) | ~13 dB (no pressure within 20 km) |
| Actual reach at ≤20 km | Full coverage (~6 dB margin) | Full coverage (~6 dB margin) |
| GPON downstream per-user peak | 2.488G ÷ 64 ≈ 38.9 Mbps | 2.488G ÷ 128 ≈ 19.4 Mbps |
| PON ports needed for 128 users | 2 | 1 |
| Typical use | Suburb / long haul / enterprise | Dense urban FTTH |
The 2.488 Gbps GPON downstream is shared across the whole PON port. If all 128 users saturate at once, the theoretical per-user peak is 2.488G ÷ 128 ≈ 19.4 Mbps; at 1:64 it is 2.488G ÷ 64 ≈ 38.9 Mbps. Double the split, halve the per-user shared bandwidth.
In practice 128 homes rarely all max out together; DBA (dynamic bandwidth allocation) schedules by demand, so residential FTTH with low concurrency barely notices. But for live streaming, video backhaul, or enterprise high-bandwidth services, the 1:128 ceiling shows up fast. XGSPON (G.987) lifts the downstream to 10G, yet the split ratio is still capped by optical power budget — more speed cannot recover lost light.
Warning: Do not spec 1:128 on the assumption that a faster PON class fixes it. XGSPON raises bandwidth but the ~21 dB splitter loss and reach constraints are unchanged; the optical budget is the hard wall.
A 1:128 split is the right call for new urban renewal FTTH: building-to-equipment-room within 20 km, clean fiber, mostly residential broadband with low concurrency. A +9 dBm OLT module with B+ ONUs leaves comfortable margin, and one PON port serves 128 households — halving OLT ports and uplink fiber cores, which clearly lowers TCO.
Step down to 1:64 or 1:32 when: distance exceeds 25 km (rural, mountain, cross-town); the cable is old or has high bend loss; video surveillance or enterprise leased lines make up a large share of users; or you want to reserve ~20% optical margin for device aging (splitter loss grows ~0.1–0.3 dB per year) and temperature drift. Beyond 25 km, the OLT is already at full C++++ power (+9 dBm) — you then upgrade the ONU to C+ (−32 dBm, 41 dB budget) or C++ (−35 dBm, 44 dB budget), or move to a long-reach scheme.
Real example: a 128-home community, 9 km from equipment room to the farthest unit, +9 dBm OLT module, B+ ONU (37 dB budget). Split loss 21 dB + connectors 2 dB + fiber 9 × 0.35 ≈ 3.2 dB = 26.2 dB, leaving 10.8 dB for aging and margin — plenty, stable even in summer heat. Push the same topology to 18 km (fiber loss 6.3 dB, total 29.3 dB) and 7.7 dB remains; B+ still holds. Past 25 km you must upgrade the ONU class.
Rayin sizes GPON split plans by calculating the budget first, then fixing the split ratio — not by copying the standard's upper limit.
What does a 1:128 GPON splitter ratio mean?
It means one OLT PON port drives 128 ONUs through a passive splitter. The GPON standard (ITU-T G.984) sets 1:128 as the maximum allowed split.
What happens if the OLT optical power is insufficient?
The end ONU receives light below its receiver sensitivity (about −28 dBm for B+), so it drops and fails to register repeatedly. A 1:128 split already costs about 21 dB; with a +9 dBm OLT module the budget is not tight, but old cable or over-distance runs burn the margin first.
How do I choose between 1:128 and 1:64?
Use 1:128 for short, dense, low-concurrency urban FTTH to save ports. Drop to 1:64, or even 1:32, for long distance, old cable, or high-bandwidth scenarios where stability matters more.
Does 1:128 crush each household's bandwidth?
At full saturation the per-user peak is about 19.4 Mbps, half of 1:64's 38.9 Mbps. Homes with low concurrency barely notice; high-bandwidth business services feel the ceiling.
A 1:128 split is a capability the standard writes down, but whether it actually runs full depends on three things lining up: optical power budget, coverage distance, and per-user bandwidth. With a +9 dBm C++++ OLT module and B+ ONUs, 1:128 is stable within the 20 km standard reach; only beyond ~25 km, on old cable, or under high bandwidth do you step back to 1:64 for peace of mind. Calculate the budget before you chase the highest split ratio. For GPON OLT and splitter planning, see Rayin's GPON OLT lineup.
